Gol Pumps 3″ Thin Submersible Well Pump – 276ft – 1080 GPH – 3 Wire – 1HP
$357.99
This 3″ thin submersible well pump from GOL Pumps can be used for water supply in wells and reservoirs. It can reach a up to 276 feet of head and is a great fit for 3.5″ diameter wells.
- Water supply from wells and reservoirs
- Comes with control box
- Rewindable motor
Applications
- For water supply from wells or reservoirs
- For domestic use
- For civil and industrial applications
- For garden use and irrigation
Operating conditions
- Maximum fluid temperature up to 95°F
- Maximum sand content : 0.25%
- Minimum well diameter : 3″
Motor and Pump
- Rewindable motor
- Single-phase:110V/60Hz or 220V/60Hz
- Equip with start control box
- Pumps are designed by casing stressed Curve tolerance according to ISO 9906
| Voltage |
110/115 volt ,220/230 volt |
|---|---|
| Brand |
GPT CO |
Description
Description
Technical Specifications
| Pump Type | Thin Submersible Pump |
| Pump Brand | GOL Pumps |
| Pump Model | 3SDM3/14 |
| Warranty | 1 Year |
| Maximum Head | 276ft |
| Minimum Head | 133ft |
| Maximum Flow | 1080 GPH |
| Minimum Fluid Temperature | 50°F |
| Maximum Fluid Temperature | 95°F |
| Maximum Ambient Temperature | 104°F |
| Discharge | 1.25″ NPT |
| Pump Material | Stainless Steel 304 |
| Pump Diameter | 3″ |
3″ GSD Total Dynamic Head
Performance Data
| MODEL | P2 | DELIVERY N = 3450 1/min | ||||||||||
| 1~
220V |
KW | HP | Q | m3/h | 0 | 0.6 | 1.2 | 1.8 | 2.4 | 3.0 | 3.6 | 4.2 |
| l/min | 0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | ||||
| 3SD M3/14 | 0.75 | 1 | H (m) | 82 | 81 | 78 | 75 | 69 | 63 | 51 | 35 | |
Dimension and Weight
| Model | DN | Dimension(inch) | Weight(lbs) | ||||||||
| 1~
110V/220V |
P | M(s) | M(t) | T(s) | T(t) | P | M(s) | M(t) | T(s) | T(t) | |
| 3SD M3/14 | 1″/1* 0.25″/1* 0.5″ | 22 | 16 | 14.5 | 38 | 36.4 | 5.1 | 16.5 | 14 | 22 | 19.2 |
| Components | Material |
| Pump external casing | AISI 304 SS |
| Delivery casing | Cast-Cu ASTM C85500 |
| Suction lantern | Cast-Cu ASTM C85500 |
| Diffuser | Plastic.PC |
| Impeller | Plastic.POM |
| Shaft | AISI 304 SS |
| Shaft coupling | AISI 304 SS |
| Wear ring | AISI 304 SS |
| Motor external casing | AISI 304 SS |
| Top cover | Cast-Cu ASTM C85500 Cast-iron ASTM NO.30 |
| Bottom support | AISI 304 SS |
| Mechanical seal | Special seal for deep well(Graphite-Ceramic/TC) |
| Shaft | AISI 303 SS-ASTM 1045/5140 |
| Seal lubricant oil | Oil for food machinery and pharmaceutic use. |
