HBI 12-15 Multi-Stage Horizontal Water Pump — 4260 GPH, 3.2 HP, 220/460 Volts, 1-1/2in. Ports, 60 Hz, 3PH, SS304
$1,168.99
The HBI series are non-self priming horizontal multistage centrifugal pumps. These pumps are designed for pumping freely flowing non-corrosive, non-explosive and non-flammable liquids. The liquids to be pumped must also be free of solid matter, sands, fibers and similar materials.
Most common non-highly corrosive watery liquids, oily liquids, hot and cold liquids can be pumped with these pumps.
The suitability of these pumps for pumping any particular liquid depends upon a number of factors such as the ph value, contents of chemicals such as chlorides, oils, the temperature of the liquids, etc.
Applications
- Water supply and pressure boosting
- Heating and cooling in industrial processes
- Industrial washing and dish-washing machines
- Pressure boosting
- Air-conditioning systems
- Fertilizer/dosing systems
Motor
- Totally enclosed and fan-cooled standard motor
- Rated speed: 3450rpm (60Hz)
- Enclosure class: IP 54
- Insulation class: F
Operating Conditions
- Liquid temperature range: 32°F ~+230°F
- Maximum ambient temperature: +104°F
- Maximum operating pressure: 142 PSI
- Maximum inlet pressure is limited by maximum operating pressure.
- Liquid: Thin, clean, non-aggressive and non-explosive liquids without solid particles or fibers.
| Brand |
GPT CO |
|---|
More Details
| Model | HBI 12-15 | |
| Material | Stainless Steel | |
| Brand | Gol Pumps | |
| Manufacturer’s Warranty | 1 year Limited Warranty | |
| Ports (in.) | Suction | 1 1/2″ |
| Discharge | 1 1/2″ | |
| Flow (GPH) | 4260 | |
| Horsepower | 3.2 | |
| Voltage – Phase | 220/460 – 3Ph | |
| Amps | 9.2/5.1 | |
| Max. Total Head (ft.) | 144 | |
| Self-Priming | No | |
| Dimensions L x W x H (in.) | 19.4 x 8 x 10.3 | |
| Product Weight (lbs.) | 52.2 | |
