CBI 4-30 Multi-Stage Horizontal Water Pump — 2400 GPH, 1.4 HP, 220/460 Volts, 1 1/4 in. Suction, 3P

The CBI series are non-self priming horizontal multistage centrifugal pumps. Pump is coupled with motor at the same shaft and mounted on a base-plate. The friendly design makes the pump suitable for installation in the small domestic or industrial water supply systems. The pump is fitted with a mechanical seal and through-going pump-motor shaft.

The discharge, suction chamber and the other parts of pump in contact with the liquid are made of stainless steel. EPDM or Viton O-rings are available as standard.

Applications

• Domestic
• Liquid transfer and circulation of liquids within light industry and farming
• Pressure boosting
• Air-conditioning systems
• Cooling systems or cooling machine
• Specialized OEM equipment

Motor

• The pump is fitted with a totally enclosed, fan-cooled, squirrel-cage motor. Three-phase motors have built-in thermal overload protection.
• Rated speed: 3450rpm (60Hz)
• Enclosure class: IP 54
• Insulation class: F

Operating Conditions

• Liquid temperature range: 32°F ~+194°F
• Maximum ambient temperature: +104°F
• Maximum operating pressure: 142 PSI
• Maximum inlet pressure is limited by maximum operating pressure.
• Liquid: Thin, clean, non-aggressive and non-explosive liquids without solid particles or fibers.
